应用领域与简单介绍/Brief Introduction：

该线由线条式丝杆洗瓶晒干合二为一机、服用液装灌线轧盖机二台单人结构，分类进行维护清洁、吹干灭菌方法处理和装灌线封膜几个作业区，旅游线可三级联动生孩子，也可单人运用。可结束淋水、超声心动图波进行维护清洁、冲水、冲气、晒干灭菌方法处理、冷却水、装灌线、理盖、戴盖、轧盖等工艺。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

特殊性/Characteristic：

选择超声难以清理波难以清理及水雾间歇性擦洗、远红外温度过高灭菌方法、多头多碇罐装与密封等系统。整线对接自行操控。的操作容易方便简洁，达到了机械一体机化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

能力指标/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
适于技术参数 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(这其中一般工作上36Kw)👍(including normal working 36 kw)
机械净含量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
