应用领域与概述：/Purpose and introduction

服用液洗烘灌轧对接线由落地式超声洁净检查波洗瓶机、隧道工程式热气 嵌套循环高压蒸汽灭菌方法烘干功能箱、服用液装罐轧盖机等形成，非常适合于 5-30ml 等有差异规 格服用液瓶的制造。可做完对制剂制造中安瓿瓶淋水、超声洁净检查波洁净、冲水、充 气、烘干功能高压蒸汽灭菌方法、冷却水、装罐、轧盖等流程布骤的对接进行。Oral liquid washing drying filling and rolling line by the vertical ultrasonic bottle-washing machine, tunnel sterilization oven hot wind cycle, oral liquid filling and other components of the rolling machine, suitable for 5-30 ml different gauge, etc Oral liquid bottle production. Can be done for ampoule bottle pour water in drug production, ultrasonic cleaning, flushing, filling gas, drying sterilization, cooling, filling and rolling cover joint operation of the process steps.

优势特点:/characteristic

◆洗瓶机通过机械厂手夹瓶，适用于种规格为的塑料瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of the bottle;◆洗瓶进行雾气喷针往返关注放入玩法，除污功效好，厉行保护生态环境系统。并存在针架防颤动传动装置，提供喷针放入玻璃瓶的更强度，减小断针的问题发生了；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶一部分水蒸气液压管路、喷针非常独立空间独立，避免出现了交差空气污染，具备GMP规范起来要；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶挤出机罗杆前还可以加装缓解块，有确保挤出机罗杆，削减碎瓶使用Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottles◆洗瓶机出瓶所采用一体化进口货此次带，对接拨块输送管液体液，工作不稳定性安全可靠In pieces out of the bottle inside the whole import synchronous belt, the connection piece of conveying liquid, stable and reliable running◆真空烘箱选择红外线煮沸管，冷库保温隔热板的表层煮沸管双层线路煮沸温暖均性好；Oven using infrared heating tube, stainless steel heating tube double heating temperature uniformity is good;◆罐装轧盖机要选配瓷砖泵、冷库保温隔热板的表层泵；In pieces filling rolling machine optional ceramic pump, stainless steel pump;◆罐装无瓶止灌，无瓶不轧盖工作。Pieces filling without bottle filling, no bottle no rolling function.◆整线适用PLC总保持、软启动器、手触屏保持系统，运动稳定性信得过。手触屏可显视各手机单机的运动心态下，各保持点的压力、大气压、气压、湿度等显视，各按钮心态下和报警显视，报警自我完善就诊和报警进行分析及去掉具体方法。使一整个种植方式高达会自动控制保持，联线体现了三机自动控制动平衡机装备，提高种植平均信得过。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. The whole production process to achieve automatic control, on-line has the compressors control balancing device, ensure production is balanced.选择玩家的要有，还可供选购：According to the needs of customers, but also available for selection:◆西门子整体、施耐德开关、三菱数控整体、台达等高端品牌操控整体；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气负荷、水的温度及超声检查波挠度、玦尘颗粒、流速同屏在线检查、报警器、记录卡、打印纸机系统。Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system.◆ORABS、CRABS、无菌检测底部隔离器体统。Mixer ORABS, CRABS, aseptic isolator system.

枝术指标：technical parameters

实用尺寸规格Cutting   dimension(ml)	5-25
生产能力production capacity(pcs/min)	350
分装精准度Filling accuracy(%)	≤ ± 2.5
灌装设备头数Fillingheads	16
轧盖头数Number of rolling   curtain	单刀20头
轧盖及格率Rolling cover   percent of pass(%)	≥ 99
总重量total weight(kg)	7500
外形尺寸boundary dimension(mm)	9920 × 2003 × 2150
